DDD-F-416F
TABLE IV Visual inspection of finished flags. - continued
EXAMINE
DEFECT
CLASSIFICATION
MAJOR MINOR
Sides & ends of duck cloth heading not properly
aligned, affecting appearance but not seriously . . . . .
X
Grommet improperly set, e.g., clinched too loosely,
allowing grommet to rotate . . . . . . . . . . . . . . . . . . . . .
X
Leather tab not positioned & attached as shown on
applicable drawing . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Headings: Type II
Sheeting all or partially missing . . . . . . . . . . . . . . . . . .
X
Heading improperly formed, e.g., both edges of the
sheeting or hoist end of flag not caught entire length
of heading seam . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Leather tabs not positioned & attached as shown on
applicable drawing . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Headings: Type III,
Hemmed heading not as shown on the applicable
Class 2
drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Leather tabs not positioned & attached as shown on
applicable drawing . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Marking
Missing, incorrect, illegible, text incomplete, marking
in wrong location, size of lettering not as specified, or
color of marking not as specified . . . . . . . . . . . . . . . .
X
Label
Text incomplete or incorrect, not attached as speci-
fied, not in location specified, or not in position speci-
fied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
1/ NOTE: Variation in the number of stitches per inch caused by the operator speeding up the machine
or pulling cloth, such as sewing over heavy places or turning corners, shall be classified as follows:
major to minor; minor to no defect.
4.3.4.2 Examination of flags for defects in dimension. Flag shall be examined for the
dimensional defects shown in TABLE V. Inspection level shall be S-3; AQL's expressed in
defects per 100 units shall be 6.5 for major defects and 15.0 total for major and minor. One
finished flag shall be equal to one unit.
TABLE V. Examination of flags for defects in dimension.
EXAMINE
DEFECT
CLASSIFICATION
MAJOR MINOR
Overall length (minus
heading)
Not within specified tolerance (± 5%) . . . . . . . . . . . . . .
X
Overall width of basic
flag
Not within specified tolerance (± 5%) . . . . . . . . . . . . . .
X
Canton dimensions
Not within specified tolerance (± 5%) . . . . . . . . . . . . . .
X
19
