DDD-F-416F
TABLE IV Visual inspection of finished flags. - continued
EXAMINE
DEFECT
CLASSIFICATION
MAJOR MINOR
Any raw edge exceeding 1/2 inch in length . . . . . . . . .
X
Loose stitch tension resulting in a loosely secured
seam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Tight stitch tension (stitches break when normal pull is
exerted in length-wise direction of seam or stitching) .
X
Stitches per inch for seams, hems, & reinforcement
patches: 1/
- 4 or more stitches less than specified . . . . . . . . . . .
X
- 1 to 3 stitches less than specified . . . . . . . . . . . . . .
X
Stitches per inch for duck cloth headings: *
- 2 or more stitches less than specified . . . . . . . . . . .
X
- 1 stitch less than specified . . . . . . . . . . . . . . . . . . . .
X
Stitches per inch for appliquéing: *
- 5 or more stitches less than specified . . . . . . . . . . .
X
- 1 to 4 stitches less than specified . . . . . . . . . . . . . .
X
Seam twisted, pleated, or puckered, seriously affect-
ing appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Seam twisted, pleated, or puckered, affecting appear
ance but not seriously . . . . . . . . . . . . . . . . . . . . . . . .
X
Broken or skipped stitches in heading seam causing
an unstitched length of 1 inch or more . . . . . . . . . . . .
X
Broken or skipped stitches in heading seam causing
an unstitched length of less than 1 inch . . . . . . . . . . .
X
Broken or skipped stitches in any other seam causing
an unstitched length of 1/2 inch or more . . . . . . . . . .
X
Broken or skipped stitches in any other seam causing
an unstitched length of less than 1/2 inch . . . . . . . . .
X
Run-offs resulting in open seam . . . . . . . . . . . . . . . . .
X
Stars (embroidery or
appliquéd design)
Broken stitches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Not appliquéd as specified . . . . . . . . . . . . . . . . . . . . . .
X
Stars inverted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Stars misplaced or in wrong location . . . . . . . . . . . . . .
X
Pattern marks used for location of design visible. . . . ..
X
Appliquéd stars not neatly trimmed . . . . . . . . . . . . . . .
X
Malformed stars seriously affecting appearance . . . . .
X
Malformed stars not seriously affecting appearance . .
X
Incorrect cartoon used . . . . . . . . . . . . . . . . . . . . . . . . .
X
Stitches not covering base cloth (front & back) . . . . . .
X
Execution of embroidery not clear & distinct . . . . . . . .
X
Incorrect span used . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Incorrect yarn used . . . . . . . . . . . . . . . . . . . . . . . . . . .
X
Evidence that sizing or stiffening agent used as an aid
in sewing had deleterious effect . . . . . . . . . . . . . . . . .
X
Hems
Nylon flags not hemmed on all edges. . . . . . . . . . . . . .
X
Raw edges not hemmed on flags other than nylon . . .
X
17
