NOT MEASUREMENT SENSITIVE
MIL-DTL-14631/9B
21 March 1997
SUPERSEDING
MIL-P-14631/9A
5 February 1992
DETAIL SPECIFICATION SHEET
PLATE, AUTOMOBILE, INDIVIDUAL, ASSISTANT SECRETARY OF THE ARMY
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and the issue of MIL-DTL-14631 listed in
that issue of the Department of Defense Index of Specifications and
Standards (DoDISS) specified in the solicitation.
MATERIAL:
Aluminum
DIMENSIONS:
BASE:
HEIGHT(Overall): 6 inches + 1/16 inch (15.24
cm + 0.16 cm)
WIDTH: 9 inches + 1/16 inch (22.86 cm + 0.16
cm)
THICKNESS: 0.064 inch + 0.003 inch (0.162 cm
+ 0.007 cm)
DEVICE (Eagle Wing to Wing Tip): 3-13/16 inches
(9.68 cm) (REF)
STAR (Circumscribed Diameter): 1 inch (2.54 cm)
(REF)
AMSC N/A
FSC 8345
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is unlimited.
1 of 2
