INCH-POUND
MIL-DTL-14631/7C
11 April 2000
SUPERSEDING
MIL-DTL-14631/7B
21 March 1997
DETAIL SPECIFICATION SHEET
PLATE, AUTOMOBILE, INDIVIDUAL, SECRETARY OF THE ARMY
Inactive for new design after 8 January 1999.
This specification is approved for use by all Departments and Agencies
of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and the issue of MIL-DTL-14631 listed in that issue of the Department of
Defense Index of Specifications and Standards (DoDISS) specified in the solicitation.
MATERIAL: Aluminum
DIMENSIONS:
BASE:
HEIGHT: (overall): 6 inches ± 1/16 inch
WIDTH: 9 inches ± 1/16 inch
THICKNESS: 0.064 inch ± 0.003 inch
COAT OF ARMS (wing tip to wing tip): 3-13/16 inches
STARS (circumscribed diameter): 1 inch
AMSC N/A
1 of 2
FSC 8345
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
